Home INDUSTRIAL PRODUCTS Valves CNG LNG LPG TOP ENTRY CRYOGENIC BALL VALVE FORGED
CNG LNG LPG CRYOGENIC GLOBE VALVE FORGED BOLTED EXTENDED BONNET $0.00
Back to products
Diaphragm Pneumatic Control Valve $0.00

CNG LNG LPG TOP ENTRY CRYOGENIC BALL VALVE FORGED

$0.00

SIZE: 1/8″~36″.

RATING: 150LB

END: BW AS PER ASME B16.25

TEMPERATURE: -196 ℃

BODY AND BONNET : A182 F316

BALL: ASTM A182 F316+HF

STEM: ASTM A182 F316

SEAT: PEEK OR HF METAL

ACTUATION: MANUAL AND GEAR

ASK MORE INFO FOR THIS PRODUCT
Compare
Add to wishlist
SKU: JV00042 Categories: INDUSTRIAL PRODUCTS, Valves Tags: Ball, Cng, Cryogenic, Entry, Forged, Lng, Lpg, Top, Valve
Share:
  • Description
  • Reviews (0)
  • Shipping & Delivery
Description



GENERAL

Size: 1/8″~36″.
Pressure Rating: 150LB~4500LB, PN6~PN750
Design Temperature: -196℃~120℃
Design Manufacture Code: ASME B16.34, BS6364, API 608, API 6D,SHELL SPE77/200
Face to Face: ASME B16.10, EN558
Connection: ASME B16.5, B16.47, EN1092, RF/RTJ. ASME B16.25 BW ASME B16.11 SW/NPT ETC.
Trims Design: Floating ball / Trunnion ball
General Applications: CNG,LNG,LPG, CO2,N2 ETC.
Safety Design: anti-blow out stem, fire proof, anti-static
Special Test if Required: Low Emission, DNV/BV/SGS TPI service is available.

MAIN TYPICAL MATERIALS LIST

BODY: ASTM A351 CF8/CF8M/CF3/CF3M, A995 4A/5A, MONEL K400/K500, H-276
BALL: ASTM A182 F304/F316/F51/F53/F55,MONEL K400/K500, H-276 hardened
EXTENDED BONNET: ASTM A351 CF8/CF8M, ASTM A182 F304/F316
STEM: F304,F316,XM-19, 17-4PH, INCONEL 718, MONEL K-500
SEAT: SPRING ENERGIZED PCTFE, PEEK OR HF METAL
OPERATOR: LEVER OR GEAR OR ACTUATOR
OTHER SPECIAL MATERIALS ARE AVAILABLE TO CUSTOMIZE.

TEST

Inspection and approval norm: API598, API6D.BS6364

QUALITY CONTROL:

100% Chemical analysis and mechanical test with raw materials of each heat numbers.
100% DPT test with the castings, partly MT or UT test, RT is always available if required.
100% hydraulic test with the shell and seal and low pressure air test.
